EuroAsia Engineering Solutions manufactures heavy-duty electric winches from 500 kg to ultra-heavy capacities, with complete customization in lifting capacity, rope length, drum design, speed, controls, braking, mounting, and environmental protection.
Manufactured as per Your Specific Requirements
500 kg to 25 Ton & above
Drum, rope, motor, brake & panel
Industrial, marine, mining, construction
Pendant, VFD, remote/wireless
Crane-duty, heavy-duty operation
Technical consultation & service
All Electric Winch Machines can be customized and manufactured by EuroAsia Engineering Solutions according to your specific site, load, lifting height, speed, duty cycle, safety, and control requirements.
We understand that every industrial lifting application is different. Our engineering team can design and manufacture winches based on your project needs, working conditions, installation space, rope capacity, power supply, lifting speed, and safety preferences.
500 kg, 1 Ton, 2 Ton, 3 Ton, 5 Ton, 10 Ton, 25 Ton, and higher capacities.
Drum capacity and rope length according to lifting height or pulling distance.
Wire rope diameter and rope grade as per load and application requirements.
Motor make, voltage, RPM, insulation class, and duty cycle (CDF).
Planetary, worm, helical, and spur multi-stage reduction systems.
Electromagnetic brake or electro-hydraulic thruster brake options.
Pendant, VFD panel, remote control, or wireless operation.
IP-55 weatherproof, flameproof, or marine-grade protection options.
Lifting lugs, foundation holes, base size, and installation layout.
Red oxide primer, enamel paint, epoxy coating, or marine protection finish.
Below is a standard range. Final specifications can be modified based on your exact requirement.
| Model | Capacity | Speed | Motor | Gear System | Control / Brake |
|---|---|---|---|---|---|
| 500 kg Electric Winch | 500 kg | 8 m/min | 1 HP | Planetary | F/R switch / Electromagnetic |
| 1 Ton Electric Winch | 1000 kg | 8 m/min | 2 HP | Planetary | VFD panel / Electromagnetic |
| 2 Ton Electric Winch | 2000 kg | 44 m/min | 20 HP | Worm Gearbox | Weatherproof panel / Electromagnetic |
| 3 Ton Electric Winch | 3000 kg | 4 m/min | 5 HP | Planetary | VFD panel / Electromagnetic |
| 5 Ton Electric Winch | 5000 kg | 7-9 m/min | 15 HP | Helical + Spur | Pendant / Thruster brake |
| 10 Ton Electric Winch | 10,000 kg | 4-6 m/min | 25 HP | Helical/Worm + Spur | Pendant / Thruster brake |
| 25 Ton Electric Winch | 25,000 kg | 5-7 m/min | 40 HP | Helical + Spur | Pendant / Thruster brake |
Manufactured using high-strength steel sections, reinforced plates, strong base frames, foundation holes, and lifting lugs for secure installation.
Drum size, flange thickness, rope winding pattern, and rope capacity can be engineered to match the required lifting height and load duty.
Planetary, worm, helical, and spur reduction arrangements can be selected as per torque, speed, duty cycle, and space constraints.
Brake type, pendant control, VFD speed control, overload protection, MCB, meters, and indicator lamps can be configured per safety requirements.
To manufacture the right winch for your application, please share these details:
Ready-to-install machine, no complex setup required.
Pre-delivery load test certified at 1.5x rated capacity.
Expert assistance from our engineering team post-delivery.
User manual, wiring diagram, and maintenance guide included.
Get a custom quote for the 500 kg Electric Winch from India's trusted manufacturer.
